Oil and Gas Correlations Calculator
for Predicting Fluid Properties

Inputs
Well Name
Oil API Gravity (°)
Oil Specific Gravity
0.8762
Gas/Oil Ratio (scf/bbl)
Gas Specific Gravity
0.8585
Bubble Point Pressure (psi)
Gas Density (lb/ft3)
0.0656
Investigated Pressure (psi)
Oil Density (lb/ft3)
54.697
Investigated Temperature (°F)
Water Density (lb/ft3)
62.428
Calculate

Results
Method Gas/Oil
Ratio
(scf/bbl)		 Bubble Point Pressure
(psi)		 Oil Formation Volume Factor

Oil
Density
(lb/ft3)
Standing 42.6 508 1.0681 52.302
Lasater 2.7 630 — —
Vasquez-Beggs 49.3 477 1.0797 51.742
Method Dead
Oil Viscosity
(cp)		 Saturated
Oil Viscosity
(cp)		 Unsaturated
Oil Viscosity
(cp)
Beal 7.3 4.8 4.7
Chew-Connally 7.3 4.8 —
Beggs-Robinson 9.4 4.6 4.6

 To view the inputs that affect a given calculation, place the cursor over the desired result.
